STAINLESS STEEL PITOT TUBE

ASME Design Meets AMCA and ASHRAE Codes

The Series 160 Stainless Steel Pitot Tube is constructed from corrosion resistant stainless steel with permanently etched insertion depth graduations for a lifetime of service. The static pressure port is parallel to the sensing tube to allow quick, easy

alignment  of  the  tube  with  air  flow.  A  universal  model  fits  the  user  supplied  3/4˝ schedule 40 pipe in any length.

FEATURES/BENEFITS

•  Low sensitivity to misalignment up to 15 degrees

•  No calibration needed due to ASHRAE tip design

•  Silver soldered connections for leak-proof operation

•  5/16˝ models rated to 1500°F (815.5°C)

APPLICATIONS

•  Monitor or control air velocity or air flow when combined with differential pressure gage, switch, or transmitter
